A high quality, stylish architectural luminaire that delivers 100% of its light downwards, making it ideal for streetscapes, parks, plazas and other public spaces where control of light pollution is an essential attribute.
- High performance optics and uniform light distribution
- Tool free maintenance
- Replaceable driver unit and LED PCB
- 20KA surge protection
- AkzoNobel powder coating which will extend the life time in harsh environments
- Voltage Input: 100 – 277VAC
- Power Factor: 0.92
- Efficacy: 125 lm/w
- CCT: 4000K
- CRI: 70
- Operating Temp: -10° to +45°C
- Ingress Protection: IP66
- Impact Rating: IK09
- Spigot Diameter (mm): 60mm
- Dimmable: Dimmable options available
- Warranty: 5 years, first 3 years inclusive of labour
- Options are special order. Please contact Lumitex for more information.
-0-10V
-Photo sensor control 3P 5P 7P NEMA socket & twist-lock receptacle
| Part Number | Wattage | Lumens (Lm) | Colour (CCT) | Beam Angle | Weight (Kg) | Frame Colour | Arms | Download IES File |
|---|---|---|---|---|---|---|---|---|
| LUMY2916043B | 60 | 6500 | 4000 | 130°x130° | 9.25 | Black (RAL9005) | 1 | Contact Lumitex |
| LUMY2926043B | 60 | 6500 | 4000 | 130°x130° | 9.25 | Black (RAL9005) | 2 | Contact Lumitex |
| LUMY2936043B | 60 | 6500 | 4000 | 130°x130° | 9.25 | Black (RAL9005) | 3 | Contact Lumitex |
| LUMY2936043G | 60 | 6500 | 4000 | 130°x130° | 9.25 | Grey (RAL9007) | 3 | Contact Lumitex |
